CS / ECS / ECJ Series
Cables, Connectors & Joint Assemblies
The CS Series cables and ECS / ECJ Series accessories are engineered for reliable signal transmission and robust interconnection in geotechnical, structural, and environmental monitoring systems. They ensure low signal loss, mechanical strength, and long-term durability in harsh field conditions — including buried installations, tunnels, dams, and outdoor environments.
All cables feature high-quality conductors, shielding, and insulation materials to minimize electromagnetic interference, moisture ingress, and mechanical wear. The ECS and ECJ accessories complement these cables by providing dependable field extensions, connections, and joints between sensors, extension leads, and data loggers.
CS-Series Cables
| Model | Description |
|---|---|
| CS-0401 Series | 7/0.34 mm annealed copper, petroleum jelly filled, galvanized steel wire armoured (0.5 mm Ø), polyethylene black sheath. |
| CS-0402 Series | 7/0.25 mm ATC twisted pairs, screened with water-blocking aluminum foil, 0.3 mm galvanized iron wire braid armoured, polyethylene black sheath. |
| CS-0403 | 7/0.2 mm silver-plated copper, 4-core screened cable (red/black/green/white) with aluminized polyester film and drain wire, PTFE gray sheath, Ø 3.5 mm, ~0.03 kg/m. |
| CS-0404 | 7/0.2 mm ATC, 4-core (red/black & white/black), foil shielded, chrome PVC gray jacket, 80°C max temp, Ø 5.6 mm, ~0.35 kg/10 m. |
| CS-0407 Series | 7/0.2 mm annealed copper, petroleum jelly filled, galvanized sheet armoured (0.5 mm Ø), polyethylene black sheath. |
| CS-0410 Series | 7/0.2 mm ATC, datalene insulated, low-capacitance, shielded cable, chrome PVC black jacket. |
| CS-0502 | 7/0.25 mm annealed copper, dual twisted pair (red/black & green/white), PVC red sheath, Ø 6.0 mm, ~0.55 kg/10 m. |
| CS-0702 | 7/0.25 mm annealed copper, dual twisted pair (red/black & green/white), aluminized polyester shield, PE insulation, drain wire, polyurethane blue sheath, Ø 6.35 mm. |
| CS-0703 | 7/0.25 mm ATC, 6-core (black/white/red/green/brown/blue), aluminized polyester shield, PE insulation, drain wire, polyurethane blue sheath, Ø 6.5 mm. |
| CS-1002 | 7/0.25 mm annealed copper, 3-core (red/black/green), aluminized polyester film, PE insulation, drain wire, polyurethane black sheath, Ø 4.7 mm. |
| CS-1102 | 7/0.2 mm annealed copper, dual twisted pair (red/black & green/white) with dual vent tube, polyurethane yellow sheath, Ø 10 mm, ~0.1 kg/m. |
| CS-1302 | 7/0.2 mm annealed tinned copper, 4-core (red/black & green/white), aluminum polyester shield, PE insulation, drain wire, Kevlar core, polyurethane yellow sheath, 85°C max temp, Ø 7 mm, ~0.53 kg/10 m. |
| CS-1303 | 7/0.25 mm ATC, dual twisted pair (red/black & green/white), foil shielded, chrome PVC gray jacket, 60°C max temp, Ø 5.5 mm, ~0.3 kg/10 m. |
ECS-Series Cable Connectors & Extensions
| Model | Description |
|---|---|
| ECS-05-Y | ABS connector for extending CS-0405-6 / CS-0406 / CS-0502 cables using butt crimp terminals. (Y = specify cable code). |
| ECS-06-Y | FRP/aluminum connector for extending other cable types using butt crimp terminals. (Y = specify cable code). |
| ECS-07 | Crimping tool compatible with ECS-05 and ECS-06 connectors. |
| ECS-08-Y | FRP/aluminum connector for extending cables with screwed terminals. (Y = specify cable code). |
ECJ-Series Cable Joint Assemblies
| Model | Description |
|---|---|
| ECJ-10-Y | Standard-duty joint for connecting two 4- or 6-core jelly-filled or water-blocking cables. Material: AISI 420 stainless steel. (Y = specify cable code). |
| ECJ-11-Y | Heavy-duty version for 4- or 6-core jelly-filled or water-blocking cable joints. Material: AISI 304 stainless steel. (Y = specify cable code). |
